XCMG 10 Cubic Meters 350HP Concrete Mixer Truck G10V Price

Name: XCMG 10 Cubic Meters 350HP Concrete Mixer Truck G10V Price
Brand: XCMG
Price: 1 USD

Quality XCMG 10 Cubic Meters 350HP Concrete Mixer Truck G10V Price wholesale

Brand Name : XCMG

Model Number : G10V

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1 Piece

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000pcs/year

Delivery Time : Full Payment 7-15 Work Days

Packaging Details : by Sea/by Bulk/by Frame/Container

Chassis model : NXG3250D5NCX

Curb mass : 14600kg

Wheelbase : 3800+1350mm

Engine : WP10.350E53

Rated power : 257Kw/r/min

Outline dimension : 9510×2500×3970mm

Contact Now

XCMG Factory 10 Cubic Meters 350HP Concrete Mixer Truck G10V Price

1.Particular mixing technology with continuous trace,original double log spiral technology with changeable lift angle and changeable screw pitch and optimized auxiliary bladesvand pressure-reducing hole design can make the operation path of the spiral in perfect state and can ensure the best concrete flowing trend in mixing drum and more uniformly discharging.

2.Optimized chassis matches with upper parts and such parts as front base andaccessory beam, rear base and tilted beam, rear base and accessory beam adopt integration design. After force bearing research and analysis and long-term application, the best position of the connecting point between tilted beam and rear base are confirmed and thus deformation and break of cross beam can be avoided effectively.

3.Feed hopper and chute are made of multilayer high-strength wear-resistant liner plate, with the service life of XCMG 10 cubic meters concrete mixer truck G10V increased by 50%.

Product Parameter

Description	Unit		Parameter value
Performance of mixing drum	Geometric volume	m³	16.8
	Max. diameter of drum	mm	2280
	Drum length	mm	5596
	Mounting tilt angle	°	13.5
	Rotary speed	r/min	0~14
	Charging speed	m³/min	≥3
	Discharging speed	m³/min	≥2
	Residual ratio of discharging	%	<0.7
	Range of slump	㎝	5~21
Hydraulic system	Oil pump		World-famous brand
	Motor		World-famous brand
	Speed reducer		World-famous brand
	Hydraulic circuit		Closed type
Water supply	Volume of water tank	L	450
	Way of water supply		Air pressure
Overall machine	Chassis brand		XCMG
	Chassis model		NXG3250D5NCX
	Steering wheel		Left steering wheel
	Curb mass	㎏	14600
	Driving type		6×4
	Wheelbase	mm	3800+1350
	PTO way		Flywheel PTO
	Outline dimension	(L×W×H)mm	9510×2500×3970
Engine	Model		WP10.350E53
	Rated power	Kw/r/min	257
	Displacement	L	9.726
	Emission standard		Euro V
