31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

Product Categories
Shandong Heavy Industry Machinery Co.,Ltd.
Contact Now

31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

  • 1
  • 2
  • 3

Brand Name : SHACMAN

Model Number : SX3255

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1 Piece

Price : Negotiation

Payment Terms : L/C, T/T, D/A, Western Union

Supply Ability : 5000pcs/year

Delivery Time : Full payment 15-20 work days

Packaging Details : Naked, frame, container

GVW : 31000kg

Engine : YC6K1344N

Power : 440HP

Emission Standard : Euro 5

Transmission : 12JSD200

Overall dimension : 10400*2550*3150mm

Contact Now

31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

Dump truck also called tipper, dumper truck which composed of chassis, hydraulic system, cargo body, PTO and so on. The hydraulic system could be HYVA or Chinese top, the material could be carbon steel or high-strengthen steel; the lifting type could be middle lifting or front lifting.

Dump is divided into 2 types which is rear tipper and side tipper. Rear tipper is more common which mainly used for transporting sand, stone, gravel, coal, earthwork and other construction materials.


Product Parameter

Vehicle Description
Overall dimension 10400*2550*3150mm
GVW 31000kg
Curb weight 15400kg
Chassis brand DONGFENG
Traction type 8*4, left hand drive
Chassis Description
Cab KC Sleeper cab,forward control type, low roof, all welded steel cab of tilt type, mechanical cab tilting, all floating and mechanical cab suspension, adjustable driver's seat, air conditioning system, central lock.
Wheel base 1850+4400+1400mm
Tire specification 12.00R20 or 315/80R22.5
Tire quantity 12+1pcs
Engine Engine model YUCHAI YC6K1344N
Emission standard Euro 5
Exhaust/output 13ml/324kw
Horse power 440hp
Gear box Model 12JSD200
Type 12 forward gears& 2 reverse, synchronized
Brake system Full air brake system, split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake.
Axle Front 7T*2-DANA brand, Elliot type, I beam section
Rear 22T*2Hub reduction, tandem axle, ratio 5.26
Suspension Front 10/10-Leaf spring
Rear 13
Battery Voltage 24V
Capacity 165A.h*2
Cylinder volume Back 220L*4
Side 120L*4
Up-parts Description
Cargo dimension 7600*2300*980mm
Material Carbon steel
Thickness Side 6mm
Bottom 8mm
Hydraulic system Chinese brand
Lifting style Front lifting


Detailed Photos
31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks

31-50ton SHACMAN Dump Trucks Dumpers 8*4 12 Wheeler Tipper Trucks
